- Bipolar Dual Output and Reduced Footprint Provides Board Designers with a Compact Power Option
- Modules Equipped with Built-in Current, Voltage and Temperature Protection
DALLAS---July 2, 2014---GE's Critical Power business (NYSE: GE) has launched its new SHHN000A3CL isolated DC-DC converters, providing board designers with a bipolar dual-output module in a compact (1-inch-by-1-inch brick) footprint. The latest addition to GE's extensive Hammerhead series of power modules, the SHHN000A3CL unit features a wide input voltage range of 9-36 volts DC and a bipolar dual output, precisely regulated output voltage at 15 volts DC and -15 volts DC, 9 watts output power and a 0.3-amp output current.
The SHHN000A3CL can be used as a traditional DC/DC module, powering applications such as insulated-gate bipolar transistors and other semiconductor device drive circuits, or in hybrid power architectures and industrial markets.
The wide input range supported by GE's SHHN000A3CL converter provides designers with increased flexibility when designing based on required input power capabilities. It also allows for sourcing consistency, equipping users with a single product that can fit into multiple sockets. The available configurations of the module---in through-hole and surface-mount formats---further add to the flexibility of the new converters.
Standard features of the SHHN000A3CL converters include remote on/off, remote sense and output voltage adjustment. In addition, the module is fully self-protected with output over-current and over-voltage, over-temperature and input under-voltage shutdown control. Available optional features include negative or positive on/off logic and surface-mount connections.
The outputs of the SHHN000A3CL are fully isolated from the input, allowing versatile polarity configurations and grounding connections. The unit's built-in filtering for both input and output minimizes the need for external filtering components and reduces the overall solution footprint.
Key features and benefits of the SHHN000A3CL isolated DC-DC converters:
- Wide input voltage range (9-36 volts DC).
- Space-efficient, low-profile footprint (1-inch-by-1-inch brick).
- Flexible configuration with surface-mount and through-hole versions available.
- Built-in current, voltage and temperature protection.
- Wide-operating temperature range (-40 to 85 C).
Availability and pricing:
The SHHN000A3CL DC-DC converter is now available in original equipment manufacturer quantities, with pricing beginning at $8.20. For more information, please call +1 877 546 3243 or +1 972 244 9288.
GE's Critical Power business provides mission-critical applications with end-to-end power product and service solutions specifically designed to maximize uptime while improving energy efficiency. The solutions offered by the Critical Power business add to GE's broader Industrial Solutions portfolio of leading technologies designed for the delivery, management and optimization of electrical power for customers across multiple industries. To learn more about GE's Critical Power business, visit: www.gecriticalpower.com.
GE (NYSE: GE) works on things that matter. The best people and the best technologies taking on the toughest challenges. Finding solutions in energy, health and home, transportation and finance. Building, powering, moving and curing the world. Not just imagining. Doing. GE works. For more information, visit the company's website at www.ge.com.
Follow GE's Critical Power business on Twitter @GEcriticalpower.
